Hasegawa 07564 - 1:48 AH-64E Apache Guardian

Plastic model kit of the AH-64E Apache Guardian attack helicopter in 1:48 scale

Hasegawa 07564 is a kit for self-assembly representing the American attack helicopter AH-64E Apache Guardian – the latest development of the Apache family. The aircraft combines heavy armament, advanced sighting and observation systems and good battlefield survivability.

The model can be built as the AH-64E or the AH-64D Block II (late version). Special parts reproduce the pointed rotor-blade tips and the upward-facing engine exhausts, while photo-etched parts represent the exhaust deflectors and cooling-intake covers.

What's in the box:

• Plastic sprues with fuselage, rotor and armament parts
• Clear parts for the cabin glazing
• Photo-etched parts: exhaust deflectors and cooling-intake covers
• Parts to build the AH-64E or the AH-64D Block II (late version)
• Waterslide decal sheet for 3 US Army marking options
• Illustrated assembly instructions

Specifications:

• Scale: 1:48
• Catalogue number: 07564
• Manufacturer: Hasegawa
• Assembled length: approx. 370 mm, main rotor diameter: approx. 305 mm
• Difficulty level: intermediate

Note: The kit does not include glue, paints or modelling tools. The model is intended for self-assembly.

Assembly:

A model of moderate difficulty, with photo-etched parts and a choice of version to build. Before starting it is worth deciding whether to build the AH-64E or the AH-64D Block II, as this affects the selection of parts. The cockpit and interior are best painted before the fuselage is closed. Working with photo-etched parts calls for cyanoacrylate glue and precise tweezers.

Helicopters of this type are usually painted in a single dark olive shade; the instructions provide paint suggestions for each option. The model can be finished with a matt varnish, with the detail and panels emphasised using a wash.

Tools required:

• Modelling nippers for removing parts from the sprues
• Modelling knife or scalpel
• Files and sandpaper for cleaning up sprue-gate marks
• Plastic cement and cyanoacrylate glue for the photo-etched parts
• Precise modelling tweezers
• Brushes in various sizes
• Modelling paints (acrylic or enamel)
• A wash to bring out the detail

About the helicopter – Boeing AH-64 Apache:

The AH-64 Apache is an American attack helicopter that entered service in the 1980s and has become one of the most recognisable combat helicopters in the world. The two-seat aircraft is designed to engage armoured vehicles, support ground forces and destroy point targets.

The AH-64E Apache Guardian version is the latest development, fitted with more powerful engines, composite rotor blades, an improved drivetrain and modern avionics. Helicopters of this version are also adapted to work together with unmanned aircraft.

Original helicopter specifications (AH-64E Apache Guardian):

• Crew: 2 (pilot and weapons operator)
• Powerplant: two General Electric T700 turboshaft engines
• Main rotor diameter: approx. 14.63 m
• Length (rotors turning): approx. 17.73 m
• Maximum speed: approx. 290 km/h
• Armament: a 30 mm cannon, unguided rockets and guided missiles

About the manufacturer – Hasegawa:

Hasegawa is a Japanese manufacturer of model kits based in Shizuoka, a city regarded as the centre of the Japanese modelling industry. The company has been active since the 1940s and has developed its range of injection-moulded plastic kits since the 1960s. Hasegawa is best known for its aircraft models in 1:72 and 1:48 scale, valued for finely reproduced, subtly recessed panel lines and good parts fit. A hallmark of the brand is its frequent limited editions with dedicated decal sheets representing specific, often commemorative aircraft. The range also includes ship, vehicle and car models as well as modelling accessories. Hasegawa kits are recognised and available among modellers worldwide.
